FoxModel2002Modified Class Reference

#include <FoxModel2002Modified.hpp>

Inherits AbstractCardiacCell.

Collaboration diagram for FoxModel2002Modified:

[legend]

List of all members.

Public Member Functions
	FoxModel2002Modified (boost::shared_ptr< AbstractIvpOdeSolver > pSolver, boost::shared_ptr< AbstractStimulusFunction > pIntracellularStimulus)
	~FoxModel2002Modified (void)
double	GetIIonic ()
void	EvaluateYDerivatives (double var_environment__time, const std::vector< double > &rY, std::vector< double > &rDY)

---

Detailed Description

Generated from CellML, and P_Ca parameter modified.

Definition at line 24 of file FoxModel2002Modified.hpp.

---

Constructor & Destructor Documentation

FoxModel2002Modified::FoxModel2002Modified	(	boost::shared_ptr< AbstractIvpOdeSolver >	pSolver,
		boost::shared_ptr< AbstractStimulusFunction >	pIntracellularStimulus
	)

Constructor

Parameters:

	pSolver	is a pointer to the ODE solver
	pIntracellularStimulus	is a pointer to the intracellular stimulus

Generated from CellML, and P_Ca parameter modified.

Definition at line 24 of file FoxModel2002Modified.cpp.

References AbstractCardiacCell::Init(), and AbstractOdeSystem::mpSystemInfo.

FoxModel2002Modified::~FoxModel2002Modified

(

void

)

Destructor

Definition at line 34 of file FoxModel2002Modified.cpp.

---

Member Function Documentation

void FoxModel2002Modified::EvaluateYDerivatives	(	double	var_environment__time,
		const std::vector< double > &	rY,
		std::vector< double > &	rDY
	)			[virtual]

Evaluate the derivatives of the state variables

Parameters:

	var_Environment__time	the current time, in milliseconds
	rY	current values of the state variables
	rDY	to be filled in with derivatives

Implements AbstractOdeSystem.

Definition at line 218 of file FoxModel2002Modified.cpp.

References AbstractOdeSystem::DumpState(), AbstractCardiacCell::GetStimulus(), AbstractCardiacCell::mSetVoltageDerivativeToZero, and AbstractOdeSystem::rGetVariableNames().

double FoxModel2002Modified::GetIIonic

(

)

[virtual]

Calculates the ionic current

Returns:

the total ionic current

Implements AbstractCardiacCell.

Definition at line 39 of file FoxModel2002Modified.cpp.

References AbstractOdeSystem::rGetStateVariables().

---

The documentation for this class was generated from the following files:

• /tmp/release_2.0/heart/src/odes/ionicmodels/FoxModel2002Modified.hpp
• /tmp/release_2.0/heart/src/odes/ionicmodels/FoxModel2002Modified.cpp
