PetscTools Class Reference

#include <PetscTools.hpp>

Collaboration diagram for PetscTools:

List of all members.

Static Public Member Functions

static void ResetCache ()

static bool IsSequential ()

static bool IsParallel ()

static unsigned GetNumProcs ()

static unsigned GetMyRank ()

static bool AmMaster ()

static bool AmTopMost ()

static void Barrier (const std::string callerId="")

static void BeginRoundRobin ()

static void EndRoundRobin ()

static Vec CreateVec (int size, int localSize=PETSC_DECIDE, bool ignoreOffProcEntries=true)

static Vec CreateVec (std::vector< double > data)

static Vec CreateAndSetVec (int size, double value)

static void SetupMat (Mat &rMat, int numRows, int numColumns, unsigned rowPreallocation, int numLocalRows=PETSC_DECIDE, int numLocalColumns=PETSC_DECIDE, bool ignoreOffProcEntries=true)

static bool ReplicateBool (bool flag)

static void ReplicateException (bool flag)

static void DumpPetscObject (const Mat &rMat, const std::string &rOutputFileFullPath)

static void DumpPetscObject (const Vec &rVec, const std::string &rOutputFileFullPath)

static void ReadPetscObject (Mat &rMat, const std::string &rOutputFileFullPath, Vec rParallelLayout=NULL)

static void ReadPetscObject (Vec &rVec, const std::string &rOutputFileFullPath, Vec rParallelLayout=NULL)

static void Terminate (const std::string &rMessage, const std::string &rFilename, unsigned lineNumber)

Static Public Attributes

static const unsigned MASTER_RANK = 0

Static Private Member Functions

static void CheckCache ()

Static Private Attributes

static bool mPetscIsInitialised = false

static unsigned mNumProcessors = 0

static unsigned mRank = 0

Detailed Description

A helper class of static methods.

Definition at line 65 of file PetscTools.hpp.

Member Function Documentation

static void PetscTools::CheckCache ( ) [inline, static, private]

Private method makes sure that (if this is the first use within a test) then PETSc has been probed

Definition at line 83 of file PetscTools.hpp.

References mNumProcessors, and ResetCache().

Referenced by AmMaster(), AmTopMost(), Barrier(), GetMyRank(), GetNumProcs(), IsParallel(), and IsSequential().

void PetscTools::ResetCache ( ) [static]

Reset our cached values: whether PETSc is initialised, how many processors there are, and which one we are.

Definition at line 47 of file PetscTools.cpp.

References mNumProcessors, mPetscIsInitialised, and mRank.

Referenced by CheckCache().

bool PetscTools::IsSequential ( ) [static]

Just returns whether there is one process or not.

Definition at line 82 of file PetscTools.cpp.

References CheckCache(), and mNumProcessors.

Referenced by AbstractCardiacTissue< ELEMENT_DIM, SPACE_DIM >::AbstractCardiacTissue(), AbstractNonlinearElasticitySolver< DIM >::AllocateMatrixMemory(), CylindricalHoneycombMeshGenerator::CylindricalHoneycombMeshGenerator(), DistanceMapCalculator< ELEMENT_DIM, SPACE_DIM >::DistanceMapCalculator(), FormDebugHead(), HoneycombMeshGenerator::HoneycombMeshGenerator(), AbstractBidomainSolver< ELEMENT_DIM, SPACE_DIM >::InitialiseForSolve(), PCTwoLevelsBlockDiagonal::PCTwoLevelsBlockDiagonalCreate(), VtkMeshWriter< ELEMENT_DIM, SPACE_DIM >::SetParallelFiles(), SetupMat(), VtkMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFilesUsingMesh(), and AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFilesUsingMesh().

bool PetscTools::IsParallel ( ) [static]

Just returns whether there is more than one process.

Definition at line 88 of file PetscTools.cpp.

References CheckCache(), and mNumProcessors.

Referenced by DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::ComputeMeshPartitioning(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::ConstructFromMeshReader(), AbstractMesh< ELEMENT_DIM, SPACE_DIM >::GetDistributedVectorFactory(), GenericEventHandler< 13, HeartEventHandler >::HeadingsImpl(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::MetisLibraryNodePartitioning(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::ParMetisLibraryNodePartitioning(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::PetscMatrixPartitioning(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::ReorderNodes(), GenericEventHandler< 13, HeartEventHandler >::ReportImpl(), and ExecutableSupport::ShowParallelLaunching().

unsigned PetscTools::GetNumProcs ( ) [static]

Returns total number of processors

Definition at line 94 of file PetscTools.cpp.

References CheckCache(), and mNumProcessors.

unsigned PetscTools::GetMyRank ( ) [static]

Return our rank.

If PETSc has not been initialized, returns 0.

Definition at line 100 of file PetscTools.cpp.

References CheckCache(), and mRank.

bool PetscTools::AmMaster ( ) [static]

Just returns whether it is the master process or not.

If not running in parallel, always returns true.

Definition at line 106 of file PetscTools.cpp.

References CheckCache(), MASTER_RANK, and mRank.

bool PetscTools::AmTopMost ( ) [static]

Just returns whether it is the right-most process or not.

If not running in parallel, always returns true.

Definition at line 112 of file PetscTools.cpp.

References CheckCache(), mNumProcessors, and mRank.

Referenced by DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::ConstructFromMeshReader(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::PetscMatrixPartitioning(), AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFilesUsingMesh(), and AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFilesUsingParallelMesh().

void PetscTools::Barrier ( const std::string callerId = "" ) [static]

If MPI is set up, perform a barrier synchronisation. If not, it's a noop.

Parameters:

callerId

only used in debug mode; printed before & after the barrier call

Definition at line 122 of file PetscTools.cpp.

References CheckCache(), GetMyRank(), and mPetscIsInitialised.

void PetscTools::BeginRoundRobin ( ) [static]

Call at the start of a block of code that should be executed by each process in turn.

Definition at line 137 of file PetscTools.cpp.

References Barrier(), and GetMyRank().

Referenced by GenericEventHandler< 13, HeartEventHandler >::ReportImpl(), and ExecutableSupport::ShowParallelLaunching().

void PetscTools::EndRoundRobin ( ) [static]

Call at the end of a block of code that should be executed by each process in turn.

Definition at line 148 of file PetscTools.cpp.

References Barrier(), GetMyRank(), and GetNumProcs().

Referenced by GenericEventHandler< 13, HeartEventHandler >::ReportImpl(), and ExecutableSupport::ShowParallelLaunching().

Vec PetscTools::CreateVec	(	int	size,
		int	localSize = `PETSC_DECIDE`,
		bool	ignoreOffProcEntries = `true`
	)			`[static]`

Create a vector of the specified size. SetFromOptions is called.

Parameters:

	size	the size of the vector
	localSize	the local number of items owned by this process
	ignoreOffProcEntries	whether to ignore entries destined to be stored on a separate processor when assembling (eliminates global reductions).

Definition at line 186 of file PetscTools.cpp.

Referenced by AbstractNonlinearElasticitySolver< DIM >::AllocateMatrixMemory(), AbstractNonlinearAssemblerSolverHybrid< ELEMENT_DIM, SPACE_DIM, PROBLEM_DIM >::ComputeJacobianNumerically(), PseudoEcgCalculator< ELEMENT_DIM, SPACE_DIM, PROBLEM_DIM >::ComputePseudoEcgAtOneTimeStep(), CreateAndSetVec(), CreateVec(), DistributedVectorFactory::CreateVec(), DistributedVectorFactory::DistributedVectorFactory(), PetscMatTools::GetMatrixRowDistributed(), LinearSystem::LinearSystem(), PCBlockDiagonal::PCBlockDiagonalCreate(), PCLDUFactorisation::PCLDUFactorisationCreate(), PCTwoLevelsBlockDiagonal::PCTwoLevelsBlockDiagonalCreate(), Hdf5DataWriter::PutStripedVector(), Hdf5DataWriter::PutVector(), PetscVecTools::SetupInterleavedVectorScatterGather(), and VoltageInterpolaterOntoMechanicsMesh< DIM >::VoltageInterpolaterOntoMechanicsMesh().

Vec PetscTools::CreateVec ( std::vector< double > data ) [static]

Create a Vec from the given data.

Parameters:

data

some data

Definition at line 206 of file PetscTools.cpp.

References CreateVec().

Vec PetscTools::CreateAndSetVec	(	int	size,
		double	value
	)			`[static]`

Create a vector of the specified size with all values set to be the given constant. SetFromOptions is called.

Parameters:

	size	the size of the vector
	value	the value to set each entry

Definition at line 226 of file PetscTools.cpp.

References CreateVec().

Referenced by OdeLinearSystemSolver::OdeLinearSystemSolver(), and AbstractNonlinearAssemblerSolverHybrid< ELEMENT_DIM, SPACE_DIM, PROBLEM_DIM >::VerifyJacobian().

void PetscTools::SetupMat	(	Mat &	rMat,
		int	numRows,
		int	numColumns,
		unsigned	rowPreallocation,
		int	numLocalRows = `PETSC_DECIDE`,
		int	numLocalColumns = `PETSC_DECIDE`,
		bool	ignoreOffProcEntries = `true`
	)			`[static]`

Set up a matrix - set the size using the given parameters. The number of local rows and columns is by default PETSC_DECIDE. SetFromOptions is called.

Parameters:

	rMat	the matrix
	numRows	the number of rows in the matrix
	numColumns	the number of columns in the matrix
	rowPreallocation	the max number of nonzero entries expected on a row A value of 0 is allowed: no preallocation is then done and the user must preallocate the memory for the matrix themselves.
	numLocalRows	the number of local rows (defaults to PETSC_DECIDE)
	numLocalColumns	the number of local columns (defaults to PETSC_DECIDE)
	ignoreOffProcEntries	tells PETSc to drop off-processor entries

Todo:: #1216 Fix the 0.7 magic number

Definition at line 240 of file PetscTools.cpp.

References IsSequential().

Referenced by AbstractNonlinearElasticitySolver< DIM >::AllocateMatrixMemory(), Hdf5DataWriter::ApplyPermutation(), Hdf5DataWriter::DefineFixedDimensionUsingMatrix(), OperatorSplittingMonodomainSolver< ELEMENT_DIM, SPACE_DIM >::InitialiseForSolve(), MatrixBasedMonodomainSolver< ELEMENT_DIM, SPACE_DIM >::InitialiseForSolve(), MatrixBasedBidomainSolver< ELEMENT_DIM, SPACE_DIM >::InitialiseForSolve(), LinearSystem::LinearSystem(), DistributedTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::PetscMatrixPartitioning(), ReadPetscObject(), LinearSystem::SetPrecondMatrixIsDifferentFromLhs(), SimplePetscNonlinearSolver::Solve(), and AbstractNonlinearAssemblerSolverHybrid< ELEMENT_DIM, SPACE_DIM, PROBLEM_DIM >::VerifyJacobian().

bool PetscTools::ReplicateBool ( bool flag ) [static]

Boolean AND of a flags between processes

Parameters:

flag

is set to true on this process.

Returns:: true if any process' flag is set to true.

Definition at line 160 of file PetscTools.cpp.

Referenced by BidomainProblem< DIM >::AnalyseMeshForBath(), DistanceMapCalculator< ELEMENT_DIM, SPACE_DIM >::ComputeDistanceMap(), AbstractBoundaryConditionsContainer< ELEMENT_DIM, SPACE_DIM, PROBLEM_DIM >::HasDirichletBoundaryConditions(), ReplicateException(), CardiacSimulationArchiver< PROBLEM_CLASS >::Save(), and DistanceMapCalculator< ELEMENT_DIM, SPACE_DIM >::UpdateQueueFromRemote().

void PetscTools::ReplicateException ( bool flag ) [static]

Ensure exceptions are handled cleanly in parallel code, by causing all processes to throw if any one does.

Parameters:

flag

is set to true if this process has thrown.

Definition at line 168 of file PetscTools.cpp.

References EXCEPTION, and ReplicateBool().

void PetscTools::DumpPetscObject	(	const Mat &	rMat,
		const std::string &	rOutputFileFullPath
	)			`[static]`

Dumps a given Petsc object to disk.

Parameters:

	rMat	a matrix
	rOutputFileFullPath	where to dump the matrix to disk

Definition at line 303 of file PetscTools.cpp.

void PetscTools::DumpPetscObject	(	const Vec &	rVec,
		const std::string &	rOutputFileFullPath
	)			`[static]`

Dumps a given Petsc object to disk.

Parameters:

	rVec	a vector
	rOutputFileFullPath	where to dump the vector to disk

Definition at line 318 of file PetscTools.cpp.

void PetscTools::ReadPetscObject	(	Mat &	rMat,
		const std::string &	rOutputFileFullPath,
		Vec	rParallelLayout = `NULL`
	)			`[static]`

Read a previously dumped Petsc object from disk.

Parameters:

	rMat	a matrix
	rOutputFileFullPath	where to read the matrix from
	rParallelLayout	If provided, rMat will have the same parallel layout. Its content is irrelevant.

Todo:: : #1082 work out appropriate nz allocation.

Definition at line 333 of file PetscTools.cpp.

References SetupMat().

void PetscTools::ReadPetscObject	(	Vec &	rVec,
		const std::string &	rOutputFileFullPath,
		Vec	rParallelLayout = `NULL`
	)			`[static]`

Read a previously dumped Petsc object from disk.

Parameters:

	rVec	a vector
	rOutputFileFullPath	where to read the matrix from
	rParallelLayout	If provided, rMat will have the same parallel layout. Its content is irrelevant.

Definition at line 377 of file PetscTools.cpp.

void PetscTools::Terminate	(	const std::string &	rMessage,
		const std::string &	rFilename,
		unsigned	lineNumber
	)			`[static]`

Level 4 error (Termination). Execution cannot continue from this point and hence should be terminated (even when running with NDEBUG).

Parameters:

	rMessage	An error message to appear on the screen
	rFilename	which source file produced the termination error
	lineNumber	which line number of the source file produced the termination error

Definition at line 402 of file PetscTools.cpp.

Member Data Documentation

bool PetscTools::mPetscIsInitialised = false [static, private]

Whether PETSc has been initialised.

Definition at line 69 of file PetscTools.hpp.

Referenced by Barrier(), and ResetCache().

unsigned PetscTools::mNumProcessors = 0 [static, private]

The total number of processors.

Definition at line 72 of file PetscTools.hpp.

Referenced by AmTopMost(), CheckCache(), GetNumProcs(), IsParallel(), IsSequential(), and ResetCache().

unsigned PetscTools::mRank = 0 [static, private]

Which processors we are.

Definition at line 80 of file PetscTools.hpp.

Referenced by AmMaster(), AmTopMost(), GetMyRank(), and ResetCache().

const unsigned PetscTools::MASTER_RANK = 0 [static]

As a convention, we consider processor 0 the master process

Definition at line 96 of file PetscTools.hpp.

Referenced by AmMaster().

The documentation for this class was generated from the following files:

global/src/parallel/PetscTools.hpp
global/src/parallel/PetscTools.cpp
