TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM > Class Template Reference
#include <TrianglesMeshWriter.hpp>
Public Member Functions | |
| TrianglesMeshWriter (const std::string &rDirectory, const std::string &rBaseName, const bool clearOutputDir=true) | |
| void | SetWriteFilesAsBinary () |
| void | WriteFiles () |
| void | WriteElementsAsFaces () |
| void | WriteFacesAsEdges () |
| template<class T> | |
| void | WriteItem (out_stream &pFile, unsigned itemNumber, const std::vector< T > &dataPacket, unsigned attribute=UINT_MAX) |
| virtual | ~TrianglesMeshWriter () |
Detailed Description
template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
class TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >
A concrete mesh writer class that writes Triangle output files.
Definition at line 41 of file TrianglesMeshWriter.hpp.
Constructor & Destructor Documentation
| TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::TrianglesMeshWriter | ( | const std::string & | rDirectory, | |
| const std::string & | rBaseName, | |||
| const bool | clearOutputDir = true | |||
| ) | [inline] |
Constructor.
- Parameters:
-
rDirectory the directory in which to write the mesh to file rBaseName the base name of the files in which to write the mesh data clearOutputDir whether to clean the directory (defaults to true)
Definition at line 39 of file TrianglesMeshWriter.cpp.
| TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::~TrianglesMeshWriter | ( | ) | [inline, virtual] |
Destructor.
Definition at line 48 of file TrianglesMeshWriter.cpp.
Member Function Documentation
| void TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::SetWriteFilesAsBinary | ( | ) | [inline] |
Switch this mesh write to write binary files
(set to write ascii files in the constructor)
Definition at line 53 of file TrianglesMeshWriter.cpp.
References AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::mFilesAreBinary.
Referenced by AbstractTetrahedralMesh< SPACE_DIM, SPACE_DIM >::save().
| void TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFiles | ( | ) | [inline, virtual] |
Write mesh data to files.
- Todo:
- throw a warning if this is the case? (#1784)
Implements AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >.
Definition at line 59 of file TrianglesMeshWriter.cpp.
References ElementData::AttributeValue, AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextBoundaryElement(), AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextCableElement(), AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextElement(), AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextNode(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumBoundaryFaces(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumCableElements(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumElements(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumNodes(), ChasteBuildInfo::GetProvenanceString(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mBaseName, AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::mFilesAreBinary, AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mpOutputFileHandler, ElementData::NodeIndices, OutputFileHandler::OpenOutputFile(), TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteElementsAsFaces(), TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFacesAsEdges(), and TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteItem().
| void TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteElementsAsFaces | ( | ) | [inline] |
Write elements as faces (used in the case ELEMENT_DIM== SPACE_DIM-1)
Definition at line 247 of file TrianglesMeshWriter.cpp.
References AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextElement(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumElements(), ChasteBuildInfo::GetProvenanceString(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mBaseName, AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::mFilesAreBinary, AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mpOutputFileHandler, OutputFileHandler::OpenOutputFile(), and TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteItem().
Referenced by TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFiles().
| void TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFacesAsEdges | ( | ) | [inline] |
Write faces as edges (used in the case ELEMENT_DIM==2, SPACE_DIM==3)
Definition at line 290 of file TrianglesMeshWriter.cpp.
References AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNextBoundaryElement(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::GetNumBoundaryFaces(), ChasteBuildInfo::GetProvenanceString(), AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mBaseName, AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::mFilesAreBinary, AbstractMeshWriter< ELEMENT_DIM, SPACE_DIM >::mpOutputFileHandler, ElementData::NodeIndices, OutputFileHandler::OpenOutputFile(), and TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteItem().
Referenced by TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFiles().
| void TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteItem | ( | out_stream & | pFile, | |
| unsigned | itemNumber, | |||
| const std::vector< T > & | dataPacket, | |||
| unsigned | attribute = UINT_MAX | |||
| ) | [inline] |
Write a line (ascii format) to a specific file stream Templated over std::vector dataPacket contents of unsigned or doubles.
- Parameters:
-
pFile Pointer to file stream itemNumber Index of the element, node or face dataPacket List of unsigneds (for node indices) or doubles (for node locations) attribute An attribute (defaults to UINT_MAX for no attribute when writing elements as faces)
Definition at line 335 of file TrianglesMeshWriter.cpp.
References AbstractTetrahedralMeshWriter< ELEMENT_DIM, SPACE_DIM >::mFilesAreBinary.
Referenced by TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteElementsAsFaces(), TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFacesAsEdges(), and TrianglesMeshWriter< ELEMENT_DIM, SPACE_DIM >::WriteFiles().
The documentation for this class was generated from the following files:
- mesh/src/writer/TrianglesMeshWriter.hpp
- mesh/src/writer/TrianglesMeshWriter.cpp
