AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM > Class Template Reference

#include <AbstractTwoBodyInteractionForce.hpp>

Inherits AbstractForce< ELEMENT_DIM, SPACE_DIM >.

Inherited by GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >.

Collaboration diagram for AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >:

Public Member Functions
	AbstractTwoBodyInteractionForce ()
bool	GetUseCutOffLength ()
void	SetCutOffLength (double cutOffLength)
double	GetCutOffLength ()
virtual c_vector< double, SPACE_DIM >	CalculateForceBetweenNodes (unsigned nodeAGlobalIndex, unsigned nodeBGlobalIndex, AbstractCellPopulation< ELEMENT_DIM, SPACE_DIM > &rCellPopulation)=0
void	AddForceContribution (AbstractCellPopulation< ELEMENT_DIM, SPACE_DIM > &rCellPopulation)
virtual void	OutputForceParameters (out_stream &rParamsFile)
Protected Attributes
bool	mUseCutOffLength
double	mMechanicsCutOffLength
Private Member Functions
template<class Archive >
void	serialize (Archive &archive, const unsigned int version)
Friends
class	boost::serialization::access

Detailed Description

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>
class AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >

An abstract class for two-body force laws.

Definition at line 46 of file AbstractTwoBodyInteractionForce.hpp.

Constructor & Destructor Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::AbstractTwoBodyInteractionForce ( ) [inline]

Constructor.

Definition at line 40 of file AbstractTwoBodyInteractionForce.cpp.

Member Function Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

void AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::AddForceContribution ( AbstractCellPopulation< ELEMENT_DIM, SPACE_DIM > & rCellPopulation ) [inline, virtual]

Overridden AddForceContribution() method.

Parameters:

rCellPopulation

reference to the cell population

Todo:: this could be tidied by using the rGetNodePairs for all populations and moving the below calculation into the MutableMesh.

Implements AbstractForce< ELEMENT_DIM, SPACE_DIM >.

Definition at line 68 of file AbstractTwoBodyInteractionForce.cpp.

References AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::CalculateForceBetweenNodes(), EXCEPTION, AbstractCentreBasedCellPopulation< ELEMENT_DIM, SPACE_DIM >::rGetNodePairs(), MeshBasedCellPopulation< ELEMENT_DIM, SPACE_DIM >::SpringsBegin(), and MeshBasedCellPopulation< ELEMENT_DIM, SPACE_DIM >::SpringsEnd().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>

virtual c_vector<double, SPACE_DIM> AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::CalculateForceBetweenNodes	(	unsigned	nodeAGlobalIndex,
		unsigned	nodeBGlobalIndex,
		AbstractCellPopulation< ELEMENT_DIM, SPACE_DIM > &	rCellPopulation
	)			`[pure virtual]`

Calculates the force between two nodes.

Note that this assumes they are connected and is called by rCalculateVelocitiesOfEachNode()

Parameters:

	nodeAGlobalIndex	index of one neighbouring node
	nodeBGlobalIndex	index of the other neighbouring node
	rCellPopulation	the cell population

Returns:: The force exerted on Node A by Node B.

Implemented in GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >.

Referenced by AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::AddForceContribution().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

double AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::GetCutOffLength ( ) [inline]

Get the cutoff length.

Returns:: mCutOffLenght

Definition at line 62 of file AbstractTwoBodyInteractionForce.cpp.

References AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mMechanicsCutOffLength.

Referenced by GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >::CalculateForceBetweenNodes().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

bool AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::GetUseCutOffLength ( ) [inline]

Whether the force is using a cut of length.

Returns:: mUseCutOffLength

Definition at line 48 of file AbstractTwoBodyInteractionForce.cpp.

References AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mUseCutOffLength.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

void AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::OutputForceParameters ( out_stream & rParamsFile ) [inline, virtual]

Overridden OutputForceParameters() method.

Parameters:

rParamsFile

the file stream to which the parameters are output

Implements AbstractForce< ELEMENT_DIM, SPACE_DIM >.

Reimplemented in BuskeAdhesiveForce< DIM >, BuskeElasticForce< DIM >, GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >, RepulsionForce< DIM >, CryptProjectionForce, LinearSpringWithVariableSpringConstantsForce< DIM >, GeneralisedLinearSpringForce< DIM >, and GeneralisedLinearSpringForce< 2 >.

Definition at line 129 of file AbstractTwoBodyInteractionForce.cpp.

References AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mMechanicsCutOffLength, and AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mUseCutOffLength.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>

template<class Archive >

void AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::serialize	(	Archive &	archive,
		const unsigned int	version
	)			`[inline, private]`

Archive the object and its member variables.

Parameters:

	archive	the archive
	version	the current version of this class

Reimplemented from AbstractForce< ELEMENT_DIM, SPACE_DIM >.

Reimplemented in BuskeAdhesiveForce< DIM >, BuskeElasticForce< DIM >, GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >, RepulsionForce< DIM >, CryptProjectionForce, LinearSpringWithVariableSpringConstantsForce< DIM >, GeneralisedLinearSpringForce< DIM >, and GeneralisedLinearSpringForce< 2 >.

Definition at line 59 of file AbstractTwoBodyInteractionForce.hpp.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>

void AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::SetCutOffLength ( double cutOffLength ) [inline]

Use a cutoff point, ie specify zero force if two cells are greater than the cutoff distance apart.

Parameters:

cutOffLength

the cutoff to use

Definition at line 54 of file AbstractTwoBodyInteractionForce.cpp.

References AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mMechanicsCutOffLength, and AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mUseCutOffLength.

Friends And Related Function Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>

friend class boost::serialization::access [friend]

Needed for serialization.

Reimplemented from AbstractForce< ELEMENT_DIM, SPACE_DIM >.

Reimplemented in BuskeAdhesiveForce< DIM >, BuskeElasticForce< DIM >, GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >, RepulsionForce< DIM >, CryptProjectionForce, LinearSpringWithVariableSpringConstantsForce< DIM >, GeneralisedLinearSpringForce< DIM >, and GeneralisedLinearSpringForce< 2 >.

Definition at line 51 of file AbstractTwoBodyInteractionForce.hpp.

Member Data Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>

double AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mMechanicsCutOffLength [protected]

Mechanics cut off length.

Definition at line 72 of file AbstractTwoBodyInteractionForce.hpp.

Referenced by AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::GetCutOffLength(), AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::OutputForceParameters(), AbstractTwoBodyInteractionForce< ELEMENT_DIM, ELEMENT_DIM >::serialize(), and AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::SetCutOffLength().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM = ELEMENT_DIM>

bool AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::mUseCutOffLength [protected]

Whether to have zero force if the cells are far enough apart.

Definition at line 69 of file AbstractTwoBodyInteractionForce.hpp.

Referenced by GeneralisedLinearSpringForce< ELEMENT_DIM, SPACE_DIM >::CalculateForceBetweenNodes(), AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::GetUseCutOffLength(), AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::OutputForceParameters(), AbstractTwoBodyInteractionForce< ELEMENT_DIM, ELEMENT_DIM >::serialize(), and AbstractTwoBodyInteractionForce< ELEMENT_DIM, SPACE_DIM >::SetCutOffLength().

The documentation for this class was generated from the following files:

cell_based/src/population/mechanics/AbstractTwoBodyInteractionForce.hpp
cell_based/src/population/mechanics/AbstractTwoBodyInteractionForce.cpp
