RampedQuarterStimulusCellFactory< CELL, DIM > Class Template Reference
#include <AbstractConvergenceTester.hpp>
Inherits AbstractCardiacCellFactory< DIM >.
Public Member Functions | |
| RampedQuarterStimulusCellFactory (double meshWidth, unsigned numElemAcross, double fullStim=-1e7) | |
| AbstractCardiacCellInterface * | CreateCardiacCellForTissueNode (Node< DIM > *pNode) |
Private Attributes | |
| std::vector< boost::shared_ptr < SimpleStimulus > > | mpStimuli |
| double | mMeshWidth |
| double | mStepSize |
| unsigned | mLevels |
Detailed Description
template<class CELL, unsigned DIM>
class RampedQuarterStimulusCellFactory< CELL, DIM >
RampedQuarterStimulusCellFactory stimulates a quarter of a mesh of width mMeshWidth ie all the cells in 0 < x <= mMeshWidth/4
Definition at line 78 of file AbstractConvergenceTester.hpp.
Constructor & Destructor Documentation
| RampedQuarterStimulusCellFactory< CELL, DIM >::RampedQuarterStimulusCellFactory | ( | double | meshWidth, | |
| unsigned | numElemAcross, | |||
| double | fullStim = -1e7 | |||
| ) | [inline] |
Constructor.
- Parameters:
-
meshWidth x-width of mesh numElemAcross this allows us to deduce the mesh step size. fullStim the maximum stimulus level
Definition at line 99 of file AbstractConvergenceTester.hpp.
References RampedQuarterStimulusCellFactory< CELL, DIM >::mLevels, and RampedQuarterStimulusCellFactory< CELL, DIM >::mpStimuli.
Member Function Documentation
| AbstractCardiacCellInterface* RampedQuarterStimulusCellFactory< CELL, DIM >::CreateCardiacCellForTissueNode | ( | Node< DIM > * | pNode | ) | [inline] |
- Returns:
- a newly createdcell model
- Parameters:
-
pNode Pointer to node object
Definition at line 121 of file AbstractConvergenceTester.hpp.
References Node< SPACE_DIM >::GetPoint(), RampedQuarterStimulusCellFactory< CELL, DIM >::mLevels, AbstractCardiacCellFactory< DIM >::mpSolver, RampedQuarterStimulusCellFactory< CELL, DIM >::mpStimuli, AbstractCardiacCellFactory< DIM >::mpZeroStimulus, and RampedQuarterStimulusCellFactory< CELL, DIM >::mStepSize.
Member Data Documentation
unsigned RampedQuarterStimulusCellFactory< CELL, DIM >::mLevels [private] |
The number of stimulated levels covering 0 <= x < mMeshWidth/4. Note that the nodes on the quarter level are not included and are unstimulated
Definition at line 90 of file AbstractConvergenceTester.hpp.
Referenced by RampedQuarterStimulusCellFactory< CELL, DIM >::CreateCardiacCellForTissueNode(), and RampedQuarterStimulusCellFactory< CELL, DIM >::RampedQuarterStimulusCellFactory().
double RampedQuarterStimulusCellFactory< CELL, DIM >::mMeshWidth [private] |
Width (x-width) of mesh
Definition at line 84 of file AbstractConvergenceTester.hpp.
std::vector< boost::shared_ptr<SimpleStimulus> > RampedQuarterStimulusCellFactory< CELL, DIM >::mpStimuli [private] |
define a new vector of stimuli - one for each step in x-direction
Definition at line 82 of file AbstractConvergenceTester.hpp.
Referenced by RampedQuarterStimulusCellFactory< CELL, DIM >::CreateCardiacCellForTissueNode(), and RampedQuarterStimulusCellFactory< CELL, DIM >::RampedQuarterStimulusCellFactory().
double RampedQuarterStimulusCellFactory< CELL, DIM >::mStepSize [private] |
Step size of mesh is derived from the width and the number of elements across
Definition at line 86 of file AbstractConvergenceTester.hpp.
Referenced by RampedQuarterStimulusCellFactory< CELL, DIM >::CreateCardiacCellForTissueNode().
The documentation for this class was generated from the following file:
- heart/src/convergence/AbstractConvergenceTester.hpp
