TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator Class Reference

#include <TetrahedralMesh.hpp>

Collaboration diagram for TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator:
Collaboration graph
[legend]

List of all members.

Public Member Functions

Node< SPACE_DIM > * GetNodeA ()
Node< SPACE_DIM > * GetNodeB ()
bool operator!= (const typename TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator &rOther)
EdgeIterator & operator++ ()
 EdgeIterator (TetrahedralMesh &rMesh, unsigned elemIndex)

Private Attributes

std::set< std::pair< unsigned,
unsigned > > 		mEdgesVisited
TetrahedralMesh & mrMesh
unsigned mElemIndex
unsigned mNodeALocalIndex
unsigned mNodeBLocalIndex

Detailed Description

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
class TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator

Iterator over edges in the mesh.

This class takes care of the logic to make sure that you consider each edge exactly once.

Definition at line 347 of file TetrahedralMesh.hpp.

Constructor & Destructor Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator ( TetrahedralMesh &  rMesh,
unsigned  elemIndex
) [inline]

Constructor for a new edge iterator.

Parameters:
rMesh The mesh
elemIndex An element index

Definition at line 703 of file TetrahedralMesh.cpp.

References AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetElement(), AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetNumAllElements(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mEdgesVisited, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeALocalIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeBLocalIndex, and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mrMesh.

Member Function Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
Node< SPACE_DIM > * TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeA (  )  [inline]
Returns:
a pointer to the node in the mesh at end A of the edge.

Definition at line 620 of file TetrahedralMesh.cpp.

References TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgesEnd(), AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetElement(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeALocalIndex, and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mrMesh.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
Node< SPACE_DIM > * TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeB (  )  [inline]
Returns:
a pointer to the node in the mesh at end B of the edge.

Definition at line 628 of file TetrahedralMesh.cpp.

References TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgesEnd(), AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetElement(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeBLocalIndex, and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mrMesh.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
bool TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator!= ( const typename TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator &  rOther  )  [inline]
Returns:
comparison not-equal-to.
Parameters:
rOther edge iterator with which comparison is made

Definition at line 636 of file TetrahedralMesh.cpp.

References TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeALocalIndex, and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeBLocalIndex.

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator & TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++ (  )  [inline]

Prefix increment operator.

Returns:
reference to incremented object

Definition at line 644 of file TetrahedralMesh.cpp.

References AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetElement(), AbstractElement< ELEMENT_DIM, SPACE_DIM >::GetNodeGlobalIndex(), AbstractTetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::GetNumAllElements(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mEdgesVisited, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeALocalIndex, TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeBLocalIndex, and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mrMesh.

Member Data Documentation

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
std::set< std::pair<unsigned, unsigned> > TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mEdgesVisited [private]

Keep track of what edges have been visited. Each edge is stored as a pair of ordered indices.

Definition at line 385 of file TetrahedralMesh.hpp.

Referenced by TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator(), and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
unsigned TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mElemIndex [private]

Element index.

Definition at line 389 of file TetrahedralMesh.hpp.

Referenced by TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeA(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeB(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator!=(), and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
unsigned TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeALocalIndex [private]

Index of one node on the edge.

Definition at line 390 of file TetrahedralMesh.hpp.

Referenced by TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeA(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator!=(), and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
unsigned TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mNodeBLocalIndex [private]

Index of the other node on the edge.

Definition at line 391 of file TetrahedralMesh.hpp.

Referenced by TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeB(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator!=(), and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++().

template<unsigned ELEMENT_DIM, unsigned SPACE_DIM>
TetrahedralMesh& TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::mrMesh [private]

The mesh.

Definition at line 387 of file TetrahedralMesh.hpp.

Referenced by TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::EdgeIterator(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeA(), TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::GetNodeB(), and TetrahedralMesh< ELEMENT_DIM, SPACE_DIM >::EdgeIterator::operator++().

The documentation for this class was generated from the following files:
